KSC Electric Industrial Limit Switches Manufacturer

SM31NP11-21/SM31NS11-21

Inquiry PREV NEXT

· Sub-body style

· Modular

· IP67 Waterproof model

Model:
SM31NP11-21: Snap Action
SM31NS11-21 : Slow Action

Operating Speed:	0.05mm-2m/sec
Operating Frequency:	Mechanical:120ops/min Electrical:30ops/min
Insulation Resistance:	>100mΩ@500V DC
Contact Resistance:	<25mΩ
Rated Current/Voltage:	10A(EN60947-5-1)
Electrical Rating:	AC15 A600/ DC13 Q300
Dielectric Strength:	1000VAC for 1 min between non-continuous terminals 2500VAC for 1 min between each terminal and ground
Service Life:	Mechanically 10,000,000 Electrically 500,000
Operating Temperature:	-25~80℃(-13~176°F) without formation of ice
Humidity:	<95%RH
Cable:	5 core: 0.75mm² 7 core: 0.5mm² 9 core: 0.34mm²
Degree of protection:	IP67
