KSC Electric Industrial Limit Switches Manufacturer

SN6170

Inquiry PREV NEXT

Feature
Specification

* Positive Opening of NC contacts
* Screw terminals with self-lifting clamps for easy wiring
* Latch/Reset function
* Galvanically separated contacts
* Custom pull force for different applications

Operating Speed:	0.05mm-0.5m/sec
Operating Frequency:	Mechanical:120ops/min Electrical:30ops/min
Insulation Resistance:	>100MΩ @ 500V DC
Rated Current/Voltage:	10A/600V AC (EN60947-5-1)
Electrical Rating:	UL/cUL Listed(E216958) for AC15 A600/ DC13 Q300
Service Life:	Mechanically 10,000,000 Electrically 500,000
Operating Temperature:	-25~80℃(-13~176°F) without formation of ice
Degree of protection:	IP65/IP67
