KSC Electric Industrial Limit Switches Manufacturer

FS-71-10N-W

Inquiry PREV

Feature
Specification

* Robust Glass Fiber Reinforced Plastics housing
* Pedal available in IP20 and IPX8
* Each footboard may control triggers
* Uses in the medical service and industrial field

Operating Speed:	60 ops/min
Insulation Resistance:	>100mΩ@500VDC
Contact Resistance:	<25mΩ
Rated Current/Voltage:	10A/15A 1/2HP 250VAC
Inrush Current:	Complies with IEC60947-5-1:AC15/DC 13
Dielectric Strength:	1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Service Life:	Mechanically 1,000,000 (operations) Electrically 500,000(operations)
Operating Temperature:	-30~+80(-22~+176)
Degree of Protection:	IP20/NEMA 1 OR IPX8/NEMA 4,4X,6,6P(add-w suffix)
