FS-91-10-W

Inquiry NEXT

Feature
Specification

* Robust glass fiber reimforced plastics or metal die cast body
* Compact Design for Industrial and Medical Application
* Different electrical ratings available

Operating Speed:	60 ops/min
Insulation Resistance:	>100mΩ@500VDC
Contact Resistance:	<25mΩ
Rated Current/Voltage:	10A, 125/250VAC (Model: FS9X-10) 15A, 125, 250, 480VAC(Model: FS9X-15) 20A, 125, 250, 480VAC(Model: FS9X-20) 25A, 125, 250, 480VAC(Model: FS9X-25)
Dielectric Strength:	1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Service Life:	Mechanically 1 x107 (operations) Electrically 5 x105 (operations)
Operating Temperature:	-20~+80oC (-4~176oF)
Degree of Protection:	IP20 and IP68 (for Model: FS9X-10W)
