KSC Electric Industrial Limit Switches Manufacturer

FSBM-1

Inquiry

Feature
Specification

* Zinc die cast base
* Compact size
* Ergonomic low profile design
* Easy to clean
* High mechanical stability
* Soft touch button with light operating force

Operating Frequency:	60 ops/min
Insulation Resistance:	>100mΩ@500V DC
Contact Resistance:	<25mΩ(initial)
Rated Current/Voltage:	5A or 10A 0-250V
Dielectric Strength:	1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Service Life:	Mechanically 1 x106 (operations) Electrically 5 x105 (operations)
Operating Temperature:	-20~+80oC (-4~176oF)
Degree of Protection:	IPX8 (NEMA 4, 4x, 6, 6P)
