Home > Products > Medical Foot Switches > FSC-6 Series Medical Potentiometer Foot Switches > FSC-61

FSC-61

FSC-61
Inquiry PREV
  • Feature
  • Specification

* Robust aluminum alloy die cast body
* Provide a variable resistance output
* UL/CSA/CE and CCC approved
* Threaded hole available in: PG13.5, M20x1.5 and 1/2NPT

Operating Frequency: 60 ops/min
Insulation Resistance: >100mΩ@500V DC
Contact Resistance: <25mΩ(initial)
Rated Current/Voltage: 10A/250VAC
Inrush Current: Complies with IEC947-5-1: AC15/DC13
Dielectric Strength: 1000VAC for 1 min between current carrying parts
2500VAC for 1 min between non-current carrying parts
Service Life: Mechanically 1 x106 (operations)
Electrically 5 x105 (operations)
Potentiometer 2.5x105 (operations)
Operating Temperature: -30~+80oC (-22~176oF)
Degree of Protection: IP65/NEMA 2,4,13 (IP68/NEMA 6,6P available on request)
