| Environment: |
Conforming to standards |
| Products: |
IEC 947-5-1, EN 60 947-5-1, VDE 0660-200,UL 508, CSA C22-2 |
| Machine: |
assemblies IEC 204-1, EN 60 204-1, NF C 79-130 |
| Vibration resistance SNH: |
9 gn (10É500 Hz), SNB : 25 gn (10É500 Hz) conforming to IEC 68-2-6 |
| Shock resistance SNH: |
68 gn, SNH-37 : 30 gn (18 ms), SNB : 50 gn conforming to IEC 68-2-27 |
| Electric shock protection: |
Class I conforming to IEC 536 and NF C 20-030 |
| Degree of protection: |
IP 65 |
| Cable entry: |
1/2NPT,PG13.5 |
| Rated operational characteristics: |
AC-15 ; A600 (Ue = 240 V, Ie = 3 A)
DC-13 ; Q300 (Ue = 250 V, Ie = 0.27 A) |
| conforming to IEC 947-5-1 Appendix A, EN 60 947-5-1 |
| Rated insulation voltage: |
Ui = 500 V degree of pollution 3 conforming to IEC 947-1 and VDE 0110, group C conforming to NF C 20-040
Ui = 300 V conforming to UL 508, CSA C22-2 n° 14 |
| Rated impulse withstand voltage: |
U imp = 6 kV conforming to IEC 947-1, IEC 664 |
| Positive operation: |
(Dpg. on model) N/C contacts with positive opening operation to IEC 947-5-1 Section 3, EN 60 947-5-1 (contacts 21-22 of SNB) |
| Resistance across terminals 25 m conforming to NF C 93-050 method A or IEC 255-7 category 3 |
| Short-circuit protection 10 A cartridge fuse type gG (gl) |
| Cabling Screw clamp terminals.: Clamping capacity, min. : 1 x 0.5 mm2, max. : 2 x 2.5 mm2 |
| Minimum actuation speed: |
0.001 m/minute, |
SNB Hoisting Limit Switches
