FS-1-10-W-SS

FS-1-10-W-SS
Inquiry
  • Feature
  • Specification

* Robust all stainless steel design for corrosion resistance
* With nonskid base pad and foot treadle pad
* UL/CSA/CE/CCC approved
* Custom wiring available

Operating Speed: 60ops/min
Switch rating: 10A/15A 250V AC
Contact Resistance: <25mΩ
Rated Current/Voltage: 10A/300V AC
Dielectric Strength: 1000VAC for 1 min between current carrying parts
2500VAC for 1 min between non-current carrying parts
Operating Temperature: -30 to +80℃(-4 to +176°F)
Degree of Protection: IP68(NEMA 4,4X,6,6P)
