KSC Electric Industrial Limit Switches Manufacturer

S-72

Inquiry

Feature
Specification

* Moistureproof
* 3 contact arrangements
* Long-life coil spring mechanism
* Plunger type and pressing plate type available
* 16 AWG cable applied
* Customized cable type available

Electrical
Electrical Rating:	10A,125/250VAC
Temperature Rating:	-40℃-85℃
Flammability Rating:	UL94V-0
Service Life:	Mechanical 10,000,000 (operations) Electical 5000,000 (operations)
Materials
Case Thermoplastic
Actuating Button Thermoplastic
Common erminals Silver-plated Brass
Moving Blade Silver-plated Brass
Spring Stainless steel
Auxiliary Actuators Cold-Roll steel sheet (Nickel plated)
Contacts Silver-cadmium oxide
Degree of protection:	IP67
