ZS-15GD-1

ZS-15GD-1

Inquiry

• Feature
• Specification

* Specifications Operating Speed 0.01mm-1m/sec Operating Frequency

Operating Speed:	0.01mm-1m/sec
Operating Frequency:	Mechanical:240ops/min  Electrical:20ops/min
Insulation Resistance:	>100mΩ@500V DC
Contact Resistance:	<15mΩ
Rated Voltage/Current:	15A 125/250/480VAC;3/4HP/125VAC 1.5HP/250VAC (UL file E321073)
Dielectric Strength:	1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non- current carrying parts
Service Life:	Mechanically 1 x107 (operations)  Electrically 5 x105 (operations)
Operating Temperature:	-25~+80oC (-13~176oF)
Humidity:	<95％RH
Degree of protection:	IP67
