FSB-2/3 Series Medical Foot Switches

Overview
Selection Guide
Products List
Download

Features:

* Ergonomic low profile design
* Button available 2 to 3
* Easy to clean
* High mechanical stability
* Soft touch button with light operating force

Installation dimensions:

Specifications:

Operating Frequency:	60ops/min
Insulation Resistance:	>100mΩ@500VDC
Contact Resistance:	<25mΩ(initial)
Rated Current/Voltage:	10A, 1/2HP, 125/250VA
Dielectric Strength:	1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Service Life:	Mechanically 1 x106 (operations) Electrically 5 x105 (operations)
Operating Temperature:	-20~+80oC (-4~176oF)
Degree of Protection:	IPX8 (NEMA 4, 4x, 6, 6P)

Operating Frequency:	60 ops/min
Insulation Resistance:	>100mw@500V DC
Contact Resistance:	<25mW (initial)
Rated Current/Voltage:	10A, 1/2HP, 125/250VA
Dielectric Strength:	1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Service Life:	Mechanically 1 x106 (operations) Electrically 5 x105 (operations)
Operating Temperature:	-20~+80oC (-4~176oF)
Degree of Protection:	IPX8 (NEMA 4, 4x, 6, 6P)

NO.	Subject	PDF Download
1	FSB-2/3 Series Medical Foot Switches	Download
